Fluorescence Microscopy and Imaging Center
Table of Contents
- Zeiss LSM 980 inverted confocal microscope with AiryScan
- Zeiss LSM 880 inverted confocal microscope with AiryScan
- Zeiss LSM 780 inverted confocal microscope
- Zeiss LSM 710 inverted confocal microscope
- Zeiss Lightsheet 7
- Andor Dragonfly Spinning Disk Confocal
- Zeiss Colibri LED inverted epifluorescent microscope
- Automated inverted epifluorescent microscope
- Inverted epifluorescent microscope
Zeiss LSM 980 inverted confocal microscope with AiryScan
- AiryScan2 Super Resolution & LSM plus
- AI sample finder for quick tile scan set up
- Laser Lines: 405, 445, 488, 514, 561, 594, 639, 730
- Long term time-lapse: Incubation with variable CO2
- Near IR excitation 730nm with emission out to 900nm
- User Guide for Zeiss LSM 980 inverted confocal microscope with AiryScan User Guide for Zeiss LSM 980 inverted confocal microscope with AiryScan (4MB)
Zeiss LSM 880 inverted confocal microscope with AiryScan
- AiryScan Super Resolution
- Fluorescence Correlation Spectroscopy
- Laser Lines: 405, 458, 488, 514, 561, 594, 633
- Long term time-lapse: Incubation with variable CO2
- Zeiss LSM 880 inverted confocal microscope with AiryScan User Guide (601KB)
Zeiss LSM 780 inverted confocal microscope
- 355nm Laser for DNA Breaks
- Short term time-lapse: Stage incubator with 5% CO2
- Laser Lines: 355, 405, 458, 488, 514, 561, 594, 633
- Zeiss LSM 780 inverted confocal microscope (702KB)
Zeiss LSM 710 inverted confocal microscope
- Multi-Photon laser
- Incubation Chamber with 5% CO2
- Laser Lines: 405, 458, 488, 514, 561, 633
- Zeiss LSM 710 inverted confocal microscope (614KB)
Zeiss Lightsheet 7
- Image Optically Cleared Specimens up to 2cm
- Temperature and CO2 incubation for live specimens
- Dual side illumination with pivot scan
- Dual sCMOS cameras
- 405nm, 445nm, 488nm, 515nm, 561nm, and 638nm laser excitation
Andor Dragonfly Spinning Disk Confocal
- dSTORM capability
- Dual Cameras (EMCCD and sCMOS) with fast acquisition times
- Full incubation with CO2
- TIRF Microscopy
Zeiss Colibri LED inverted epifluorescent microscope
- Fast (100fps) 4megapixel sCMOS camera
- 7 color LED fluorescence excitation
- Tile Scan
- Objectives: 5X, 10X, 20X, 40X, 63X Oil
Automated inverted epifluorescent microscope
- Tile Scan
- Runs using Zen Blue
- Objectives: 5x, 10x, 20x, 40x Dry, 63x Oil
- B/W or color camera
Inverted epifluorescent microscope
- No signup needed
- Runs using Axiovision
- B/W or Color Camera
- Objectives: 2.5x, 4x, 10x, 20x, 40x Dry, 60x Oil
Photographs Provided by Steven R. McCaw, NIEHS Multimedia Servcies
